| Parameter | HPE ProLiant DL360 Gen10 Plus |
| Category | Rack Server |
| Manufacturer | Hewlett Packard Enterprise (HPE) |
| Model | DL360 Gen10 Plus |
| Form Factor | 1U Rack |
| Processor Family | Intel Xeon Scalable 3rd Generation (Ice Lake) |
| Processor Sockets | Up to 2 |
| Compatible Processor Models | Intel Xeon Silver, Gold, and Platinum (4300/5300/6300/8300 Series) |
| Max Processor Cores | Up to 40 cores per CPU |
| Clock Speed Range | 2.0 GHz to 3.6 GHz (depending on model) |
| CPU Socket Type | LGA4189 |
| Memory Type | DDR4 Registered ECC RDIMM / LRDIMM |
| Memory Slots | 32 DIMM slots (16 per CPU) |
| Memory Speed | Up to 3200 MHz |
| Maximum Memory Capacity | Up to 8 TB (with LRDIMM) |
| Storage Bays | Up to 10 SFF / 8 SFF NVMe / 4 LFF |
| Storage Interface | SAS, SATA, NVMe |
| Storage Controllers | HPE Smart Array P408i-a, P816i-a, or E208i-a |
| RAID Support | RAID 0, 1, 5, 6, 10, 50, 60 |
| Hot-Swap Drive Support | Yes |
| Network Interface | 4x 1GbE embedded ports + FlexibleLOM / OCP 3.0 slot |
| Network Adapter Options | 1GbE, 10GbE, 25GbE, 100GbE (Intel X710, Broadcom, Mellanox) |
| GPU Support | 1 Single-Width GPU (e.g., NVIDIA A2, T4) |
| GPU Interface | PCIe 4.0 x16 |
| Expansion Slots | Up to 3 PCIe 4.0 slots |
| Power Supply Options | Dual Hot-Plug Redundant PSU (500W / 800W / 1600W Titanium) |
| Power Efficiency | 80 Plus Platinum / Titanium |
| Management | HPE iLO 5 with Intelligent Provisioning |
| Security | Silicon Root of Trust, TPM 2.0, Secure Boot |
| Operating System Support | Windows Server 2019/2022, RHEL 8/9, SUSE, Ubuntu, VMware ESXi 7.x / 8.x |
| Warranty | 3 Years 3-3-3 (Parts/Labour/Onsite) |
| MOQ (Minimum Order Quantity) | 1 Unit |
| Ideal Use Cases | Virtualization, Database, Web Hosting, Cloud Infrastructure |
